Controllers for water treatment and swimming pools
The series of electronic equipments of Cullwater are been created to front the new exigencies of the water treatment and swimming pools.
The controllers are extremely easy to install and to manage, permitting for example the control of the pH, the free chlorine, the Redox potential, the electrical conductivity, the temperature and the flow rate.
Controllers
DIN series
PH-D: controller for measuring and regulation of pH
MV-D: controller for measuring and regulation of Redox potential
CL-D: controller for measuring and regulation of free Chlorine
MS-D: controller for measuring and regulation of Electrical Conductivity
O2-D: controller for measuring and regulation of Dissolved Oxygen
°C -D: controller for measuring and regulation of Temperature
Technical features of the DIN series controllers:
- Power supply: 230 V – 50/60 Hz
- Protection: IP 40
- Regulation: 2 set point (on-off, proportional)
- Current output: 0/4-20 mA
- Dimensions in mm. (L x H x P): 105 x 90 x 55
For wall installations
PH-S: controller for measuring and regulation of pH
MV-S: controller for measuring and regulation of Redox potential
CL-S: controller for measuring and regulation of free Chlorine
MS-S: controller for measuring and regulation of Electrical Conductivity
O2-S: controller for measuring and regulation of Dissolved Oxygen
PHMV-S: controller for measuring and regulation of pH and Redox
PHCL-S: controller for measuring and regulation of pH and free Chlorine
PHMS-S: controller for measuring and regulation of pH and Electrical Conductivity
PHMVCL°C-S: controller for measuring and regulation of pH, Redox, free Chlorine and Temperature
Technical features of wall installation controllers:
- Power supply: 90-260 V – 50/60 Hz
- Protection: IP 65
- Regulation: 2 set point (on-off, proportional)
- Current output: 0/4-20 mA
- Dimensions in mm. (L x H x P): 235 x 205 x 105
